GENERAL SPECIFICATIONS

HULL LENGTH: 110'-3"

HULL WIDTH: 64'-6"

HULL DEPTH: 9'-0"

LENGTH OVERALL: 113'-0"

WIDTH OVERALL: 70'-0"

FOOTING LENGTH: 26'-0"

FOOTING WIDTH: 14'-0"

FOOTING DEPTH: 2'-0"

LEG LENGTH OVERALL: 175'-0"

LEG DIAMETER: 54" O.D.

LEG THICKNESS: 3/4"

LEG MATERIAL: API 5L-X65

JACKING SPECIFICATIONS

JACKS PER LEG QTY: SIX

JACKING RATING / JACK: 65.75 S-TONS

HOLDING RATING / JACK: 87.67 S-TONS

JACKING RATING / LEG: 394.5 S-TONS

HOLDING RATING / LEG: 526.0 S-TONS

TOTAL JACKS QTY: EIGHTEEN

TOTAL JACKING RATING: 1183.5 S-TONS

TOTAL HOLDING RATING: 1578.1 S-TON

CAPACITIES

FUEL OIL CAPACITY: 8,547 GAL

POTABLE WATER CAPACITY: 13,625 GAL

JACKING HYDRAULIC OIL: 1,472 GAL

CRANE HYDRAULIC OIL: 690 GAL

ACCOMMODATIONS

ACCOMMODATION CREW: 4 MEN

ACCOMMODATION VIP: 1 MAN

ACCOMMODATION PACS: 25 MEN

ACCOMMODATION TOTAL: 30 MEN

MIF Class 175 Liftboat

Outboard Profile

Main Deck

Levels 1, 2 & 3
